Takeoff weight
1191 g
Max takeoff weight
2000 g
Wheelbase
397 mm
Size(L*W*H)
230*130*108mm(folded)
457*558*108mm(unfolded)
Maximum service ceiling altitude
7000 m
Max ascent speed
8 m/s (Ludicrous)
Max descent speed
4 m/s (Ludicrous)
Max horizontal flight speed
20m/s (Ludicrous)
Max flight distance (no wind)
25 km
Max tilt angle
33° (Ludicrous)
Max angular velocity
120°/s
Max flight time (no wind)
40 min
Max hovering time (no wind)
35 min
Operating temperature range
-10℃ ~ 40℃
Maximum resistance to wind
Level 8
Operating frequency
902-928MHz (FCC Only)
2.400-2.4835GHz
5.725-5.850GHz (non-Japan)
5.650-5.755GHz (Japan Only)
Transmission power
900M
FCC/ ISED:≤31dBm
2.4G
FCC/ ISED:≤32dBm
SRRC/CE/MIC/RCM:≤20dBm
5.8G (non-Japan) ; 5.7G (Japan)
FCC/ISED/SRRC/MIC:≤33dBm
CE/ RCM:≤14dBm
Hovering accuracy
Vertical: ±0.1 m (when the visual positioning is working normally);
±0.5 m (when GPS works normally)
Horizontal: ±0.3 m (when the visual positioning is working normally);
±1.5 m (when GPS works normally)
GNSS
GPS/Beidou/Glonass/Gallieo
Internal storage
8GB
SD storage
max. support 256GB (UHS-3 or Class 10)
